Aristomat GL
ARISTO once again increases the productivity of their large GL-machines. With a completely new steering system, the throughput for large format processing with these production machines has been improved considerably. This makes the plotter even more interesting for automated volume production, from panel or roll materials.
Designed cutting table
Impresses with its functional design and concentration on the basic essentials: a from all sides freely accessible work surface, extremely robust traverse bridge with minimal protruding at the sides and belt drive in all axis for slip-free drive. Powerful AC-servomotors and the modern CAN-Bus-steering technique enable the high throughput.
Powerful vacuum technique
Up to 264 controllable vacuum zones hold even the smallest of remnants safely on the work surface.
Simple operating
With the easy-to-use operable Cutter ControlPanel software, available in many languages, the ARISTOMAT cutters are controlled from PC. The windows user interface offers the user all graphical informations of the cutting data. With the mobile control pad essential functions such as navigation or setting the origin allow an effective operation.
Various tool heads
Combinable single and multifunctional tool heads with tangentially controlled tool holders and a large number of precision tools, offer the possibility of processing a varied choice of materials. This variety of possibilities for material processing can be supplemented with the automatic measuring system AutomaticEye and the providing of data via mobile barcode reader.
Material transport
To automate the processing, the machines can be supplemented with a revolving conveyor, a powered unwinding device for continual material transportation of roll materials. The machines also can be converted to ProductionLineCutters (PLC) with integrated loading and/or unloading table.
Designed cutting table
Impresses with its functional design and concentration on the basic essentials: a from all sides freely accessible work surface, extremely robust traverse bridge with minimal protruding at the sides and belt drive in all axis for slip-free drive. Powerful AC-servomotors and the modern CAN-Bus-steering technique enable the high throughput.
Powerful vacuum technique
Up to 264 controllable vacuum zones hold even the smallest of remnants safely on the work surface.
Simple operating
With the easy-to-use operable Cutter ControlPanel software, available in many languages, the ARISTOMAT cutters are controlled from PC. The windows user interface offers the user all graphical informations of the cutting data. With the mobile control pad essential functions such as navigation or setting the origin allow an effective operation.
Various tool heads
Combinable single and multifunctional tool heads with tangentially controlled tool holders and a large number of precision tools, offer the possibility of processing a varied choice of materials. This variety of possibilities for material processing can be supplemented with the automatic measuring system AutomaticEye and the providing of data via mobile barcode reader.
Material transport
To automate the processing, the machines can be supplemented with a revolving conveyor, a powered unwinding device for continual material transportation of roll materials. The machines also can be converted to ProductionLineCutters (PLC) with integrated loading and/or unloading table.
Aristomat GL 2032
- Travels: 2040 х 3200 мм.
- Outer dimensions: 2660 х 4220 х 1090 мм.
Aristomat GL 2032C
- Travels: 1940 х 3200 мм.
- Outer dimensions: 2660 х 4220 х 1090 мм.
Aristomat GL 2052
- Travels: 2040 х 5180 мм.
- Outer dimensions: 2660 х 6200 х 1090 мм.
Aristomat GL 2052C
- Travels: 1940 х 5180 мм..
- Outer dimensions: 2660 х 6200 х 1090 мм .
Aristomat GL 2072
- Travels: 2040 х 7160 мм.
- Outer dimensions: 2660 х 8180 х 1090 мм.
Aristomat GL 2072C
- Travels: 1940 х 7160 мм.
- Outer dimensions: 2660 х 8180 х 1090 мм.
Technical Specifications:
- Material clearance thickness max. 55 mm (max. 2.16 inch) depending on the tool head and protective underlay
- Speed max. 2.3 m/s (91 in/sec) - GL 2032 and GL 2032 C. max. 1.7 m/s (67 in/sec) - GL 2052 and GL 2052 C, GL 2072 and GL 2072 C.
- Input buffer PC controlled
- Static repeatability ± 0,08 mm/m @20°C
- Control circuit and drives Digital AC servo motors
- ТData format HPGL compatible, with extended command set
- ПVacuum Adjustable matrix vacuum zones
- Power supply 3-phase fixed connection, 400V, 50Hz
- Operating ARISTO control software for Windows Version 7, 8, 10 (32 bit / 64 bit) Various selectable languages. Mobile control pad.
- Safety / Certification CE-label; Emergency stop; Light barrier; Collision shut-off
- Ambient conditions
Operating temperature +10°C up to +30°C (50°F up to 86°F)
Storage temperature -15°C up to +45°C (5°F up to 113°F)
Rel. humidity 40 - 80% non-condensing
Options:
- Conveyor system with integrated unloading table (PLC-Machine)
- Motorized winding and unwinding devices for roll materials
- Material clamp system
- Various combinable tool heads
- Data base CutRecall for saving, calling and editing of all process parameters
- Intelligent camera system AutomaticEye for accurate assignment and scaling of prints
- Mobile BarcodeReader for automatic assignment of cutting data
- Projection of the cutting outline onto the material.
