Aristomat LFC
Finishing in the LFP sector is today changing. Increasing printing speeds and ever larger formats of digital printers require new manufacturing strategies in finishing processing. The ARISTOMAT LFC, specially designed for the cutting of large format roll and sheet materials, offers the conditions for an optimized work flow.
Designed cutting table
Ergonomic and functional design and concentration on the basic essentials: a from all sides freely accessible work surface, extremely robust traverse bridge with minimal protruding at the sides and belt drive in all axis for slipfree drive. Powerful AC-servomotors and the modern CAN-Bussteering technique enable the high performance.
Powerful vacuum technique
Up to 255 controllable vacuum zones ensure for best power distribution. So even smallest remnants are securely held on the work surface.
Simple operating
With the easy-to-use operable CutterControlPanel software, available in many languages, the ARISTOMAT cutters are controlled from PC. The windows user interface offers the user all graphical informations of the cutting data. With the mobile control pad essential functions such as navigation or setting the origin allow an effective operation.
Various tool heads
Combinable single and multifunctional tool heads with tangentially controlled tool holders and a large number of precision tools, offer the possibility of processing a varied choice of materials. This variety of possibilities for material processing can be supplemented with the automatic measuring system AutomaticEye and the providing of data via mobile barcode reader.
Material transport
The heavy duty version of the conveyor and individually adjustable material clamps ensure an automatic further transport of rolls and sheets. For flexible materials, optional unwinding devices allows an automatic feeding of the material from the roll onto the ARISTOMAT.
Designed cutting table
Ergonomic and functional design and concentration on the basic essentials: a from all sides freely accessible work surface, extremely robust traverse bridge with minimal protruding at the sides and belt drive in all axis for slipfree drive. Powerful AC-servomotors and the modern CAN-Bussteering technique enable the high performance.
Powerful vacuum technique
Up to 255 controllable vacuum zones ensure for best power distribution. So even smallest remnants are securely held on the work surface.
Simple operating
With the easy-to-use operable CutterControlPanel software, available in many languages, the ARISTOMAT cutters are controlled from PC. The windows user interface offers the user all graphical informations of the cutting data. With the mobile control pad essential functions such as navigation or setting the origin allow an effective operation.
Various tool heads
Combinable single and multifunctional tool heads with tangentially controlled tool holders and a large number of precision tools, offer the possibility of processing a varied choice of materials. This variety of possibilities for material processing can be supplemented with the automatic measuring system AutomaticEye and the providing of data via mobile barcode reader.
Material transport
The heavy duty version of the conveyor and individually adjustable material clamps ensure an automatic further transport of rolls and sheets. For flexible materials, optional unwinding devices allows an automatic feeding of the material from the roll onto the ARISTOMAT.
Aristomat LFC 2332/LFC 2332 C
Aristomat LFC 3332/LFC 3332 C
Aristomat LFC 5232/LFC 5232 C
Aristomat LFC 5252/LFC 5252 C
Technical Specifications:
Storage temperature -15°C up to +45°C (5°F up to 113°F)
Rel. humidity 40 - 80% non-condensing
Options:
- Travels: 2575 х 3440 мм.
- Outer dimensions: 3390 х 4785 х 1144 мм.
Aristomat LFC 3332/LFC 3332 C
- Travels: 3615 х 3440 мм.
- Outer dimensions: 4425 х 4785 х 1144 мм.
Aristomat LFC 5232/LFC 5232 C
- Travels: 5345 х 3440 мм.
- Outer dimensions: 6155 х 4785 х 1144 мм.
Aristomat LFC 5252/LFC 5252 C
- Travels: 5345 х 5420 мм.
- Outer dimensions: 6155 х 6765 х 1144 мм.
Technical Specifications:
- Material clearance thickness max. 60 mm (max. 2.36 inch) depending on the tool head and protective underlay
- Input buffer PC controlled
- Control circuit and drives Digital AC servo motors
- Data format HPGL compatible, with extended command set
- Vacuum Adjustable matrix vacuum zones
- Power supply 3-phase fixed connection, 400V, 50Hz
- Operating ARISTO software for Windows Version 7, 8, 10 (32 bit / 64 bit) Various selectable languages. Mobile control pad.
- Safety / Certification CE-label; Emergency stop; Light barrier; Collision shut-off
- Ambient conditions
Storage temperature -15°C up to +45°C (5°F up to 113°F)
Rel. humidity 40 - 80% non-condensing
Options:
- Motorized unwinding devices for roll materials
- Material clamp system
- Various combinable tool heads
- Data base CutRecall for saving, calling and editing of all material and process specific parameter settings
- Intelligent camera system AutomaticEye for the exact cutting of printed patterns
- Mobile BarcodeReader for automatic assignment of cutting data
- Projection of the cutting outline onto the material
