Aristomat TL
Clear designed cutting table
Impresses with its functional design and concentration on the basic essentials: a from all sides freely accessible work surface, extremely robust traverse bridge with minimal protruding at the sides and rack and pinion drive in all axis for slip-free drive. Powerful AC-servomotors and the modern CAN-Bussteering technique enable the high throughput.
Powerful vacuum technique
Up to 54 controllable vacuum zones hold even the smallest of remnants safely on the work surface.
Simple operating
With the easy-to-use operable Cutter ControlPanel software, available in many languages, the ARISTOMAT cutters are controlled from PC. The windows user interface offers the user all graphical informations of the cutting data. With the mobile control pad essential functions such as navigation or setting the origin allow an effective operation.
Various tool heads
Combinable single and multi-functional tool heads with tangentially controlled tool holders and a large number of precision tools, offer the possibility of a varied choice of materials to process.
This variety of possibilities for material processing can be supplemented with the automatic measuring system AutomaticEye and the providing of data via mobile barcode reader.
Material transport
To automate the processing, the machines can be supplemented with a revolving conveyor, a powered unwinding device for continual material transportation of roll materials. The machines also can be converted to ProductionLineCutters (PLC) with integrated loading and/or unloading table.
Impresses with its functional design and concentration on the basic essentials: a from all sides freely accessible work surface, extremely robust traverse bridge with minimal protruding at the sides and rack and pinion drive in all axis for slip-free drive. Powerful AC-servomotors and the modern CAN-Bussteering technique enable the high throughput.
Powerful vacuum technique
Up to 54 controllable vacuum zones hold even the smallest of remnants safely on the work surface.
Simple operating
With the easy-to-use operable Cutter ControlPanel software, available in many languages, the ARISTOMAT cutters are controlled from PC. The windows user interface offers the user all graphical informations of the cutting data. With the mobile control pad essential functions such as navigation or setting the origin allow an effective operation.
Various tool heads
Combinable single and multi-functional tool heads with tangentially controlled tool holders and a large number of precision tools, offer the possibility of a varied choice of materials to process.
This variety of possibilities for material processing can be supplemented with the automatic measuring system AutomaticEye and the providing of data via mobile barcode reader.
Material transport
To automate the processing, the machines can be supplemented with a revolving conveyor, a powered unwinding device for continual material transportation of roll materials. The machines also can be converted to ProductionLineCutters (PLC) with integrated loading and/or unloading table.
Aristomat TL 1310
Aristomat TL 1310C
Aristomat TL 1617
Aristomat TL 1617C
Aristomat TL 1625
Aristomat TL 1625C
Technical Specifications:
Storage temperature -15°C up to +45°C (5°F up to 113°F)
Rel. humidity 40 - 80% non-condensing
Options:
- Travels: 1300 х 1000 мм.
- Outer dimension: 1920 х 1760 х 1140 мм.
Aristomat TL 1310C
- Travels: 1220 х 1000 мм.
- Outer dimension: 1920 х 2140 х 1140 мм. with Conveyor.
Aristomat TL 1617
- Travels: 1600 х 1700 мм.
- Outer dimension: 2220 х 2420 х 1140 мм. with Conveyor.
Aristomat TL 1617C
- Travels: 1520 х 1700 мм.
- Outer dimension: 2220 х 2800 х 1140 мм. with Conveyor.
Aristomat TL 1625
- Travels: 1600 х 2500 мм.
- Outer dimension: 2220 х 3220 х 1140 мм. with Conveyor.
Aristomat TL 1625C
- Travels: 1520 х 2500 мм.
- Outer dimension: 2220 х 3600 х 1140 мм, with Conveyor.
Technical Specifications:
- Speed1 max. 1,130 mm/sec (45 in/sec), adjustable via software
- Acceleration1 max. 1.15 G, adjustable via software
- Material clearance thickness max. 46 mm (max. 1.8 inch) depending on the tool head and protective underlay
- Input buffer PC controlled
- Static repeatability ± 0,02 mm/m @20°C
- Control circuit and drives Digital AC servo motors
- Data format HPGL compatible, with extended command set
- Vacuum Adjustable matrix vacuum zones
- Power supply1 3-phase fixed connection, 400V, 50Hz
- Operating ARISTO control software for Windows Version 7, 8, 10 (32 bit / 64 bit) Various selectable languages. Mobile control pad.
- Safety / Certification CE-label; Emergency stop; Light barrier; Collision shut-off
- Ambient conditions
Storage temperature -15°C up to +45°C (5°F up to 113°F)
Rel. humidity 40 - 80% non-condensing
Options:
- Conveyor system with integrated unloading table (PLC-Machine)
- Motorized and manually winding and unwinding devices for roll materials
- Material clamp system
- Various combinable tool heads
- Data base CutRecall for saving, calling and editing of all process parameters
- Intelligent camera system AutomaticEye for accurate assignment and scaling of prints
- Mobile BarcodeReader for automatic process identification
- Projection of the cutting outline onto the material
