Aristomat XLR
Conception of the cutting table
ARISTO® XLR impresses with its functional design and concentration on the essentials: Work surface freely accessible from all sides, extremely robust cross rail with minimal lateral overhangs.
Powerful vacuum technique
Up to 232 controllable vacuum zones hold even the smallest of remnants safely on the work surface.
Simple operating
With the easy-to-use operable CutterControlPanel software, available in many languages, the ARISTO® cutters are controlled from PC. The windows user interface offers the user all graphical informations of the cutting data. With the mobile control pad essential functions such as navigation or setting the origin allow an effective operation.
Various tool heads
Combinable single and multifunctional tool heads with tangentially controlled tool holders and a large number of precision tools, offer the possibility of processing a varied choice of materials. Position detection with various sensors (e.g. camera), mobile hand scanner and much more round off the options.
Material transport
To automate the processing, the machines can be supplemented with a revolving conveyor, a powered unwinding device for continual material transportation of roll materials. The machines also can be converted to ProductionLineCutters (PLC) with integrated loading and/or unloading table.
ARISTO® XLR impresses with its functional design and concentration on the essentials: Work surface freely accessible from all sides, extremely robust cross rail with minimal lateral overhangs.
- Rack and pinion drive in all axes for slip-free drive
- Powerful AC servo motors
- Modern CAN bus technology for high throughput
Powerful vacuum technique
Up to 232 controllable vacuum zones hold even the smallest of remnants safely on the work surface.
Simple operating
With the easy-to-use operable CutterControlPanel software, available in many languages, the ARISTO® cutters are controlled from PC. The windows user interface offers the user all graphical informations of the cutting data. With the mobile control pad essential functions such as navigation or setting the origin allow an effective operation.
Various tool heads
Combinable single and multifunctional tool heads with tangentially controlled tool holders and a large number of precision tools, offer the possibility of processing a varied choice of materials. Position detection with various sensors (e.g. camera), mobile hand scanner and much more round off the options.
Material transport
To automate the processing, the machines can be supplemented with a revolving conveyor, a powered unwinding device for continual material transportation of roll materials. The machines also can be converted to ProductionLineCutters (PLC) with integrated loading and/or unloading table.
Aristomat XLR2233
Aristomat XLR2253
Aristomat XLR2273
Aristomat XLR2292
- Travels: 2200 x 3300 мм.
- Outer dimensions: 2886 x 4089 мм.
Aristomat XLR2253
- Travels: 2200 x 5280 мм.
- Outer dimensions: 2886 x 6069 мм.
Aristomat XLR2273
- Travels: 2200 x 7260 мм.
- Outer dimensions: 2886 x 8049 мм.
Aristomat XLR2292
- Travels: 2200 x 9240 мм.
- Outer dimensions: 2886 x 10029 мм.
Technical specifications:
- Speed. Depending on machine size, equipment and tool. 1.200 mm/s
- Acceleration. 12 m/s2 => 1,22 G
- Material clearance thickness max. 60 mm, depending on the tool head and protective underlay
- Input buffer PC controlled
- Static repeatability ± 0,02 mm/m @20°C
- Control circuit and drives Digital AC servo motors
- Data format HPGL compatible, enhanced with device-specific commands. Import of other file formats possible via the software: e.g. XML, DXF etc.
- Vacuum Up to 232 adjustable matrix vacuum zones
- Operating ARISTO controlled software for Windows 10, 11 (64 bit) Various selectable languages. Mobile control pad.
- Safety / Certification CE-label; Emergency stop; Light barrier; Collision shut-off
- Ambient conditions
Operating temperature +10°C bis +30°C
Storage temperature -15°C bis +45°C
Rel. humidity 40 - 80% non-condensing
Options:
- Conveyor system with integrated unloading table (PLC-Machine)
- Motorized winding and unwinding devices for roll materials
- Material clamp system
- Various combinable tool heads
- Data base CutRecall for saving, calling and editing of all process parameters
- Intelligent camera system AutomaticEye for accurate assignment and scaling of prints
- Mobile BarcodeReader for automatic assignment of cutting data
- Projection of the cutting outline onto the material
- Scan & nest in work area
