Bevel Cut Device
BevelCutDevice.
The BevelCutDevice can be used, for example, for the 45°, 30° and 60° cutting of materials such as X-board, Kappa, 3-fold corrugated board or rubber. This offers new possibilities for the processing of displays, rigid packaging or gaskets.
It is equipped with a controlled (Z) height and (C) turn axis. It can therefore be used parallel to the, in the packaging and gasket industry proven cutting and creasing tool head, MultiHead.
The BevelCutDevice can be used, for example, for the 45°, 30° and 60° cutting of materials such as X-board, Kappa, 3-fold corrugated board or rubber. This offers new possibilities for the processing of displays, rigid packaging or gaskets.
It is equipped with a controlled (Z) height and (C) turn axis. It can therefore be used parallel to the, in the packaging and gasket industry proven cutting and creasing tool head, MultiHead.
- 45°, 30° and 60° knife, tangential controlled
- slanted cutting into the material through simultaneous movement of the Z- and X- or Y-axis
- up to 18 mm cutting depth
- also available as single-sided cut
- controlled C-axis for the tangential drive
- controlled Z-axis for immersion to cutting depth
- combinable with other ARISTO tool heads
- available for ARISTO® GL, TL and LFC series
