P5 500
The Durst P5 500 is the most efficient 5-meter large format printer with LED curing technology for unattended production. With a printing width of 5.2 m, it is suitable for many roll-to-roll applications. An integrated roll support greatly simplifies media loading and changing. Rolls can be processed in single, dual and triple mode - in dual mode even asymmetrically.
P5 TECHNOLOGY
- Ricoh GEN5 printheads
- LED curing
- Light colors, white, varnish
RETRACTABLE MESH PRINTING SYSTEM
- Motorized belt for printing mesh media
- Easy media handling
- Fast media change
DATA BACKPRINTER
- QR/barcode printing
- In combination with H-Cut
FINISHING SYSTEM
- V-Cut
- H-Cut
- Continuous printing while cutting
- Roll to sheet function
MULTIROLL
- Dual/triple roll option
- Asymmetrical dual roll option
EASY MEDIA HANDLING
- Roll support for easy media loading
- Roll tool for axle feeding
- Built-in high effective lightbox
DOUBLE SIDED PRINTING
- Front and back registration
- For single, dual and triple roll
ROBUSTNESS
- Unattended printing
- 24/7 reliability
PRINTING SPECIFICATIONS P5 500
- Resolution: 700x1200 dpi; 900x1200 dpi
- Drop size: 7 pl
- Color channels: up to 8
MEDIA SPECIFICATIONS P5 500
- Max. printing width 5240 mm (213 in.)
- Max. roll width:
Single 5240 mm (213 in.)
Dual symmetrical 2500 mm (98 in.)
Dual asymmetrical 3200 mm + 1625 mm (126 in. + 64 in.)
Triple 1625 mm (64 in.)
- Max. roll diameter - 350 mm (13.8 in.)
- Max. roll weight:
Single 270/245 kg with carbon axle/with aluminium axle
Dual 280 kg
Triple 280 kg
