P5 250 WT

THE MOST PRODUCTIVE WATER-BASED INK MULTIPASS-PRINTER FOR CORRUGATED PACKAGING AND DISPLAYS.

The P5 250 WT incorporates the Durst Water Technology and prints from flexo quality up to supberb litho quality with odorless ink. Durst Water Technology is highly suited for a range of Corrugated Packaging and Displays applications. Durst WT Inks are completely free of hazardous labeling and comply with the strictest health and safety regulations.

PRINTING SPECIFICATIONS P5 250 WT

• Productivity: Up to 345 m²/h (3,710 sq.ft./h)
• Resolution: Up to 1000 DPI
• Drop size modulation: Variodrop Technology
• Standard colors: Cyan, Magenta, Yellow, Black, Light Cyan, Light Magenta
• Working height: 1,044 ± 20 mm (41.1 ± 0.8 in.)

MEDIA SPECIFICATIONS P5 250 WT

• Maximum printing width: 250 cm (98 in.), media dependent
• Maximum printing length: only limited by media length and type
• Maximum thickness:

up to 30 mm (1.18 in.) in manual operation

up to 10 mm (0.40 in.) with automation system

• Minimum thickness:

0,5mm (0.0039 in) in manual operation

0,5mm (0.0039 in) with automation system

• Maximum weight: up to 50 kg (110 lb)
• Minimum weight: 300g/sqm with automation system
• Minimum board size: 50 x 80cm (19,69 x 31,50 in.) W x L with automation system
