Durst P5 350/HS

THE MOST EFFICIENT 3.5 M HYBRID PRINTER IN THE MARKET.

The Durst P5 350/HS is the most efficient and versatile 3.5 m industrial large format printer with LED curing technology.

With a printing width of 350 cm(137.8 in), it is suitable for many applications on a big variety of substrates such as rolls, sheets, corrugated cardboard, and even heavy media such as plexiglass.

With the feeding & stacking system Automat the printing process can be fully automated.

Applications

Packaging:

• Displays
• Plastic & Polypropylene
• Wood
• Corrugated

Signage POP/POS:

• Billboars/Posters
• Retail
• Trade shows
• Outdoor advertising
• Special effects

Industrial:

• Industrial decoration
• Flooring
• Wall coverings
• Facades
• Furnishing

PRINTING SPECIFICATIONS P5 350/HS

• Productivity: Up to 708 m²/h (7,620 sq.ft./h)
• Resolution: Up to 1,200 dpi
• Drop size modulation: Binary
• Printheads: Ricoh Gen5
• Standard colors: Cyan, Magenta, Yellow, Black
• Additional color options: Light Cyan, Light Magenta, White, Varnish, Primer

MEDIA SPECIFICATIONS P5 350/HS

• Maximum printing width on boards: 500 mm (11.48 ft.)
• Max. board thickness: 70 mm (2.76 in.)
• Minimum board size: DIN-A3 - 29.7 x 42 cm (12x17 in.)
• Maximum printing width on 1 roll: 3,470 mm (11.38 ft.)
• Maximum printing width on 2 rolls (side by side): 1,625 mm (64 in.)
• Maximum roll weight (SingleRoll & DualRoll): 300 kg (660 lbs)
• Maximum roll diameter: Up to 420 mm (16.5 in.)
