P5 TEX iSUB
P5 TEX iSUB
The Durst P5 TEX iSUB is the new large format dye-sublimation printer with an integrated inline fixation (iSUB) technology for a 1-step direct to fabrics printing process up to 337 cm (132.6 in) printing width. The integrated features of multiroll and dual roll printing make the printer very versatile and suitable for many soft signage and fabrics applications. The drying system combined with IR and heated plates is also suitable for transfer paper printing.
The Durst P5 TEX iSUB is the new large format dye-sublimation printer with an integrated inline fixation (iSUB) technology for a 1-step direct to fabrics printing process up to 337 cm (132.6 in) printing width. The integrated features of multiroll and dual roll printing make the printer very versatile and suitable for many soft signage and fabrics applications. The drying system combined with IR and heated plates is also suitable for transfer paper printing.
PRINTING SPECIFICATIONS
- Productivity: Up to 422 sqm/h (4,120 sq.ft./h)
- Resolution: 400x600 dpi grayscale & 800x600 dpi binary
- Drop size modulation: Binary
- Printheads: Ricoh Gen5
- Standard colors: Cyan, Magenta, Yellow, Black
- Additional color options: Light Cyan, Light Magenta, Orange, Light Black
MEDIA SPECIFICATIONS
- Maximum roll width for single roll: 3 400 mm (11.15 ft.)
- Maximum roll width for dual roll: 1 625 mm (64 in.)
- Maximum roll weight: 200 kg (441 lb)
- Maximum roll diameter (Lower or Upper Position): 350 mm (13.7 in.)
- Maximum roll diameter (Lower and Upper Position):
Upper Position: 230 mm (9 in.)
Lower Position: 350 mm (13.7 in.)
- Maximum roll diameter (Lower and Upper Position):
Upper Position: 350 mm (13.7 in.)
Lower Position: 230 mm (9 in.)
